Workstations:40

Pallet size：2200*850

Pitch：2500mm

Height of operating table:650±20mm

The pallet fixture closure height:245mm±0.2

Main drive chain model:M315-P-250  ， scraping belt δ10/45Mn

Orbital arc diameter:9000mm

Production takt of design:10~~12s   ，    curing time is less than 240s

Linear speed control range:7.5~ 15m/min, stepless speed adjustment

Curing/operation station:30/10

Closing time:≤7s

Upper/lower mold heating:Heating, chiller cooling, fan 11KW. The cooling/heating exchanger is in series.
8 rows *2 sets
Temperature of drying tunnel：75C°±10C°

Heating time：90 minutes     ,  the environment temperature is 5 ℃

Dragging motor：SEW reducer /11KW  , domestic explosion-proof variable frequency motor.

Drive station/chain refueling：The automatic tanker controls the refueling time.
